Lft-Ax

Edge is a versatile track spotlight featuring an innovative L-shaped extension for enhanced positioning and adjustability. Designed for dynamic lighting applications, the extended L-angle allows for greater reach and precise beam direction, making it ideal for accent and task lighting.

Constructed from durable extruded aluminum, it ensures efficient heat dissipation and longevity. The clear glass reflector enhances light output, while multiple beam angle options of 12°, 24°, 36°, 48°, and 60° provide tailored illumination for various settings. Perfect for retail, galleries, and commercial spaces, the Edge combines flexibility with a sleek, modern aesthetic.

  • Electrical
  • Input Voltage - 180 - 280 AC 50Hz
  • Driver Type - Constant Current Driver
  • Control - Switch / DALI / Analog
  • Connection - Plug-in Type Pre-wired
  • General Characteristics
  • Appliance Class - Class 2
  • Ingress Protection - IP20
  • Photobiological Safety - RG 0 - No Risk
  • Ambient Temperature - 0 to +50° C
  • Luminaire
  • Housing Material - Die Cast Aluminium
  • Environment - Indoor
  • Mounting - Surface
  • Light Distribution - Direct
  • Body Finish - Aluminium
  • Optics - Clear Glass + Reflector
  • Driver Mount - Integrated
  • Thermal Management - Passive Cooling
  • Light Source
  • LED - Medium Power LED
  • Binning - 3 Step MacAdam
  • Luminous Efficacy - 95 Lm/W
  • Color Temperature - 3000K / 4000K / 5700K
  • CRI - &GreaterEqual≥80 (Standard) &GreaterEqual≥90 (Optional) Tunable LED (Optional)
  • UGR - <19
  • LED Life - >50,000 hours

Lunnark Lighting

Lunnark Lighting

Lunnark Lighting

Mounting Size Light Distribution Control CCT Color
